How often should maintenance tasks of GE Voulson P8 be performed?

The Voluson P8 delivers excellent image quality, ease of use, and streamlined workflow in a sleek, lightweight package. Ideal for growing practices with demanding schedules, The fully digital architecture of the Ultrasound System allows optimal usage of all scanning modes and probe types throughout the full spectrum of operating frequencies.

How often should maintenance tasks be performed?

The Customer Care Schedule specifies how often your Ultrasound System should be serviced and outlines items requiring special attention.

It is the customer's responsibility to ensure the Ultrasound System care and maintenance is performed as scheduled in order to retain its high level of safety, dependability and performance.

The service procedures and recommended intervals shown in the Customer Care Schedule assumes that you use your

Ultrasound System for an average patient load (10-12 per day) and not use it as a primary mobile Ultrasound system which is transported between diagnostic facilities

If conditions exist which exceed typical usage and patient load, then it is recommended to increase the maintenance frequencies.

Please refer to the Customer Care Schedule in the service manual for the Ultrasound System unit for the correct maintenance care schedule

Physical checks of LCD Display

Inspect the LCD Display for scratches and bad pixels.

Verify proper operation of Contrast and Brightness controls.

Where applicable, confirm that the LCD arm allows:

• swivelling the screen to the left and to the right

• folding the screen to the locked position

• release and adjustment backwards and forwards

• can be adjusted in the up/down positions.

Note: LCD Arm movement may vary and is not applicable to all Ultrasound Systems

Physical checks of Cables and Connectors

Check all internal cable harnesses and connectors for wear and secure connector seating. Pay special attention to footswitch assembly and probe strain or bend reliefs.
